hydraulic suspension driver’s seat, 4-point hydraulic suspension cab, one sleeping bed, A/C, manual window machine, metal bumper
Main Specifications
Model | SX3255DT385 | |
Driving type | 6X6 | |
Vehicle kerb mass（kg） | 15400 | |
GVW（kg） | 25000/39500 | |
Engine | WP12.420E332 | |
Displacement（L） | 11.596 | |
Horsepower（hp） | 420 | |
Fuel tank capacity（L） | 400L aluminum tank | |
Tyre | 13.00R22.5 | |
Clutch | Ø430diaphragm spring | |
Gearbox
| Transmission | 12JSD200T power take-off，12forward speeds, 2reverse speeds.
|
Max.torque（N.m） | 2000 | |
Front axle | MAN 9T front driving axle 9 MAN | |
Drive axle | MAN 16T×2 double reduction driving axle，ratio5.92
| |
Steering | ZF technology（Left-hand drive） | |
Cab | D’LONG F2000 mid-lengthened flat cab, annular window curtain, rear window, hydraulic suspension driver’s seat, 4-point hydraulic suspension cab, one sleeping bed, A/C, manual window machine, metal bumper | |
