. Widely used in geophysical exploration, oil fields, mines, electricity, water conservancy, emergency rescue, material transportation and other fields.
Parameter configuration: | |||
Drive type | 4x4 | Total mass (kg) | 9490 |
Curb weight (kg) | 4990 | Rated load (kg) | 4305 |
External dimensions (mm) length x width x height | 6910x2470x2475 | ||
Cargo box internal dimensions (mm) length x width x height | 4052x2294x550,600 | ||
Wheelbase (mm) | 3950 | Cab | Pointed head single row |
Engine | B170 33 | Gearbox | Five gears |
Front axle | 2.7 ton | Rear axle | 7 tons |
Tyre specifications | 9.00R20 | Number of leaf springs | 9/11+8 |
Front track (mm) | 1810 | Rear track (mm) | 1800 |
Approach angle/departure angle | 42.5/26 | Front overhang/rear overhang (mm) | 1065/1895 |
